Single stage monostage centrifugal pumps with closed impeller
|Impeller||Max flow m³/h||Max pressure bar||Pumped Fluids||Self-priming||Stages||Seal||ISO|
|Closed||500||10||Clean or slightly muddy liquids||No||1||Mechanical||No|
Built according to ISO standard 2858 and 5199 these sturdy and reliable pumps are available at low price coupled with the easy operation of monobloc units.
The series TCHM and TCTM of Travaini are of the highest quality, with attractive prices to the Chemical and Industry in general.
Standard explosion proof electric motors (ADPE), beside the CVE, can be installed with great cost savings and availability.
The motors are standard IEC form B5 machines allowing cost saving in purchase price and availability.
The motors are directly coupled to the pump without the provision of flexible couplings. Perfect alignment is guaranteed, less maintenance cost and longer life.
The pump shaft is supported by an independent ball bearing. The radial and axial forces do not load the electric motor bearings. This arrangement affords greater reliability and durability since there is less wear on the rotating component.
The motor is mounted on a flanged motor stool in perfect alignment. The pumps can be purchased without electric motors.
Mechanical seals are to ISO3069/UNI EN 12756. They are the same size as for the TCH and TCT pumps. There is unlimited choice of material and seal type, minimising the cost of stocking many different seal types.
The casing has a sturdy foot which offers a better distribution of force leading to greater reliability and durability.
